Cast Steel Gate Valve

Cast Steel Gate Valve

(Click to Enlarge)

Technical Specifications
Size Range15 mm to 600 mm
Class150, 300, 600
Design Standard

API 600/ BS EN ISO 15761/ ASME B16.34,

Add API 602 in Design Standard

Testing StandardAPI 598 / BS EN 12266-1
Face to FaceASME B16.10
Body & BonnetASTM A216 Gr. WCB, ASTM A217 Gr. WC6/ WC9/ C5/ C12, ASTM A352 Gr. LCB, ASTM A351 Gr. CF8/ CF8M/ CF3/ CF3M
TrimsASTM A276 TYPE 410/ 304/ 316
EndsFlanged End/ Butt Weld End
OperationHand Wheel, Gear, Pneumatic, Electrical Actuator & others as per customer requirement
Optional FeaturesIBR, Locking Arrangement, Jacketed, Cryogenic, Stem Extension
