| Technical Specifications | |
| Size Range | 15 mm to 400 mm |
| Class | 150 |
| Design Standard | API 609 Cat A |
| Testing Standard | API 598 |
| Face to Face | |
| Body & Cover | ASTM A216 Gr. WCB, ASTM A351 Gr. CF8/ CF8M/ CF3/ CF3M |
| Lining Material | PFA, FEP |
| Lining Thickness | 3mm to 5mm |
| Ends | Wafer Lug Type |
| Operation | Manual Lever, Gear Box, Pneumatic, Electric actuator & Others as per customer requirement. |
| Optional Features | Limit Switch, Solenoid Valve, Electro/Pneumatic-Pneumatic Valve Positioner, Gear Box with Locking arrangement |
