Trunnion Mounted Ball Valve

Home / Trunnion Mounted Ball Valve

(Click to Enlarge)

Technical Specifications
Size Range	150 mm to 600 mm
Class	150, 300, 600
Design Standard	BS EN ISO 17292 (BS 5351)/ ASME B16.34
Testing Standard	API 598 / BS EN 12266-1
Face to Face	ASME B16.10
Body & End Piece	ASTM A216 Gr. WCB, ASTM A352 Gr. LCB, ASTM A351 Gr. CF8/ CF8M/ CF3/ CF3M, ASTM A890/A995 4A/5A, ASTM A743 CN7M
Ball	CA 15/ CF8/ CF8M/ CF3/ CF3M/ CN7M /DUPLEX
Ends	Flanged End / Butt Weld End
Operation	Lever, Gear, Pneumatic, Electric actuator & Others as per customer requirement.
Optional Features	IBR, Locking Arrangement, Fire Safe, Metal Seat/ Soft Seat, Cryogenic, Stem Extension
