3 Piece Forged Ball Valve

(Click to Enlarge)

Technical Specifications
Size Range	15 mm to 50 mm
Class	800, 1500, 2500
Design Standard	BS EN ISO 17292
Testing Standard	API 598 / BS EN 12266-1
Face to Face	Manufacturer Standard
Body & End Piece	ASTM A105, ASTM A182 Gr. F304/ F316
Trims	ASTM A276 TYPE 410/ 304 /316
Ends	Socket Weld End, Screwed End, Butt Weld End
Operation	Lever, Gear, Pneumatic, Electric actuator & Others as per customer requirement.
Optional Features	IBR, Locking Arrangement, Fire Safe, Metal Seat/ Soft Seat, Cryogenic, Stem Extension, Nipple Extension
